Flex Update Hyundai Kia SIM2K-510 ECU by OBD (Exclusive Solution)

SIM2K-510 New Exclusive Solution is coming!!

New protocol released in Magic Motorsport Flex software version 8.28.0.0 allowing technicians to program Kefico SIM2K-510 units in OBD, following a simple, fast, and more efficient procedure.

Connect, read, modify!

Just connect the OBD cable, download the Virtual Read and start your modifications. If the Virtual Read is not available, perform a real read in OBD on Bench mode. The unit will unlock automatically.

Moreover, even CAN FD versions are now supported thanks to the new FLX4.4 adapter.



Vehicles: Hyundai · Kia

Working mode: OBD · OBD on Bench

Software: Flex 8.28.0.0

Connection:~30 seconds
Reading time: ~5 minutes
Writing time: ~10 minutes
Memories: VR / Read / Write / Checksum Maps
License: FLS0.1M/S · FLS0.5M/S



Mode 01 · OBD
Connect, read and edit

A simple and fast procedure.

01. Connect the OBD cable.

02. Download the Virtual Read.

03. Make the changes you need.



Mode 02 · OBD on Bench
On the bench, with a real read

When the Virtual Read is not available.

Use OBD on Bench mode to perform a real read of the ECU.



Also supports CAN-FD versions.

For versions using CAN-FD communication.  Requires the new CAN-FD FLX4.4 adapter.

FLEX SIM2K-510

Some of the supported vehicles



Hyundai Kona (I) OS (2017MY) 1.6L CRDi 16v MHEV 134HP

Hyundai Tucson (IV) NX4 (2020MY) 1.6l CRDi 16V 114HP

Kia Ceed (III) CD (2018MY) 1.6L CRDi 16v 134HP

Kia Sportage (V) NQ5 (2021MY) 1.6L CRDi 16v MHEV 134HP

Kia Stonic (I) YB (2017MY) 1.6L CRDi 16v 114HP





BEFORE WORKING ON A SIM2K-510, CHECK THE CAR AND DISCONNECT:

any external alarm system connected to the CAN bus
any SCR/AdBlue emulator connected to the CAN bus
any OEM multimedia system connected to the CAN bus
any other device connected to the CAN bus that is not original equipment of the car
If any of these devices is connected, communication breaks and the ECU is permanently bricked. It cannot be recovered.



Other precautions

Use a stabilised power supply (about 13 V). The unlock does not start below 12.5 V.

Never interrupt the unlock. The Flex asks for confirmation before starting.

Keep the internet connection active for the whole operation.

CAN-FD versions: writing requires the new CAN-FD adapter FLX4.4. With a Secure Gateway (“SGW detected”), connect directly to the ECU (OBD on Bench).
