What’s the difference between 2023 new Launch X431 Pro3 V+ Elite and Autel MaxiSys MS906 Pro diagnostic tool?
Check the table comparison below:
| Item | Launch X431 Pro3 V+ Elite |
Autel MS906 Pro |
| Operating system | Android 10.0 | Android 7.0 |
| Screen | 10.1 inches | 8 inch |
| Processor | 2.0GHz 4-core | Samsung Exynos 8 Core |
| Resolution | 1280*800 | 1920*1200 |
| Battery | 6300mAH | 11600mAh |
| RAM | 64GB | 128GB |
| ROM | 4GB | 4GB |
| Camera | rear 8 million pixels | Front: 5 Megapixel
Rear: 16 Megapixel |
| WiFi | 2.4GHz/5GHz (dual-band) | 2.4GHz/5GHz |
| VCI | Smartlink C 2.0 | VCI200 |
| J2534 Programming | Yes, with Smartlink VCI | Yes, with V200 VCI |
| AutoVIN | Yes | Yes |
| Software Update | 2 years free update | 1 Year free update |
| Full system diagnostic | Yes | Yes |
| ECU Coding | Yes | Yes |
| Remote diagnostics | No need 3rd party software | Need Teamviewer |
| D-PDU, DoIP, CAN FD | Yes | Need OTG and F chassis cable for Audi |
| Special functions | 50+ | 36+ |
| VAG Guided Functions | Yes | Yes |
| Reflash hidden features | Yes | Yes |
| Pre & Post scan | Yes | Yes |
| Topology Mapping | Yes | No |
| OBDII PIN Detection | Yes | No |
| Active test | Yes | Yes |
| Maintenance Data | Yes | No |
| Language support | 25+, switch in machine anytime | Contact technical support to change language |
| Add-on modules | Battery tester, videoscope, multimeter, TPMS, EV kit, Immobilizer, key programmer, ADAS, WiFi printer, Scopebox, heavy duty, Sensorbox | Oscilloscope, battery tester, videoscope |
| FCA Autoauth | Yes | Yes |
| Nissan SGW Unlock | No | Coming soon |
| Renault SGW unlock | Yes, purchase in Mall | Yes, purchase unlock service |
| Benz SGW Unlock | Yes, purchase in Mall | Yes, purchase unlock service |
In sum:
MS906 Pro has larger battery and storage, Pro3 V+ Elite has newer system, larger screen.
Pro3 V+ Elite supports Topology mapping, OBDII PIN detection, repair data, MS906Pro does not.
Pro3 V+ Elite has more add-on modules, TPMS, IMMO, scopebox, multimeter, sensorbox, EV kit, heavy duty module etc, Autel cannot do this.
Pro3 V+ Elite has more special functions and supports remote diagnosis via Smartlink C.
All depends on your need.
