Mini Pro TL886A and TL866CS in-circuit USB serial programmer are out of production and it is replaced by new TL866 II Plus programmer.
TL866II Plus vs. TL866A vs. TL866CS Programmer
| Description | TL866 II Plus | TL866A | TL866CS |
|---|---|---|---|
| Pin Dectected | YES | No | No |
| 1.8V supported | YES | No | No |
| NAND FLASH | YES | No | No |
| ISP for 24/93/25 MCU | YES | only MCU | No |
| 25 Nor Flash Maximum capacity | 512M | 128M | 128M |
| Multi Programming (4) | YES | YES | YES |
| VPP Max.Voltage | 18V | 21V | 21V |
| VCC Voltage | 1.8V-6.5V | 3.3V-6.5V | 3.3V-6.5 |
| W29C020 P+V (S) | 10.2S+2.4S | 12.9S+4.3S | 12.9S+4.3S |
| W25X80 P+V (S) | 9.3S+1.7S | 21.5S+10.3S | 21.5S+10.3S |
| W25Q64 P+V (S) | 69S+14.5S | 128S+82S | 128S+82S |
| Device List | 15000+ | 13000+ | 13000+ |
| Status | In Production | Stop Production | Stop Production |
XGecu TL866II Plus USB High Performance Programmer
Latest software version: V7.07
Update: Free online
Language: English/Chinese
Operating System: WIN 2000/WIN XP/WIN 2003/WIN 2008/WIN VISTA /WIN7/WIN8/WIN10 (32BIit/64Bit)
Support wide range of chips:
15130 supported devices from hundreds of manufacturers by 7.07 version of software (Mar. , 2018).
NAND FLASH: Samsung K9xxx, SK Hynix (ex Hynix) HY27xxx, H27xxx, Micron MT29Fxxx, NANDxxx, Spansion S34xxx, NAND Toshiba TH58NVGxxx.
Serial NAND FLASH: Micron MT29Fxxx.
Serial Flash: standard SPI, high performance Dual I/O SPI and Quad I/O SPI (25Bxxx, 25Dxxx, 25Fxxx, 25Lxxx, 25Pxxx, 25Qxxx, 25Sxxx, 25Txxx, 25Uxxx, 25Vxxx, 25Wxxx, 25Xxxx, 26Vxxx, 45PExx, MX26Lxxx ).DataFlash (AT45Dxxx, AT26Dxxx)
Parallel NOR Flash: 28Fxxx, 29Cxxx, 29Fxxx, 29BVxxx, 29LVxxx, 29Wxxx, 49Fxxx series, Samsung’sK8Pxxxx, K8Dxxxx series, …
EPROM: NMOS/CMOS, 27xxx and 27Cxxx series
EEPROM: NMOS/CMOS, 28xxx, 28Cxxx, 27EExxx series,
Serial E(E)PROM: 24XXX,25XXX series,
Microcontrollers MCS51 series:89Cxxx, 89Sxxx, 89EXXX,89VXX
Microcontrollers Atmel AVR 8bit/16bit: AT90Sxxxx, ATtiny, ATmega series
Microcontrollers Microchip PICmicro: PIC10xxx, PIC12xxx, PIC16xxx, PIC17Cxxx, PIC18xxx, PIC24xxx series
GAL Programmable logic device programming and SRAM test
I.C. Tester: TTL type: 54,74 S/LS/ALS/H/HC/HCT series; CMOS type: 4000, 4500 series;
Static RAM: 6116 ..
TL866 II Plus USB Programmer User Manual
TL866 II Plus Supported Detail Device List
Upgrade History:
Version: V7.07 Support:15130 –2018.03.17
ADD: IC to 15130
Fix: SST39LF/VFxxxx TSOP48 Pin Detect function
Fix: Some 25 serials auto selection
Version: V7.05 Support:15118 –2018.03.01
Add English instruction
Version: V7.03 Support:15118 –2018.02.26
TL866II Plus Release First.
