GM Tech2 Scanner VCI, Keypad, CANdi and RS232 Self Test Instructions

Manual: How to do GM Tech 2 clone scanner self test step-by-step

VCI self test

Keypad self test

CANdi self test

RS-232 self test



Follow the instruction in detail…



Part 1: Tech2 VCI self test

tech2-vci-self-test-1

Insert the GM card

tech2-vci-self-test-2

Connect the adapter and ready for the self test

tech2-vci-self-test-3

Go to the main menu and select F4: Tool options

tech2-vci-self-test-4

F3: Self test

tech2-vci-self-test-5

Exit to continue

tech2-vci-self-test-6

Select the function for self test

tech2-vci-self-test-7

Here, press F2: Automated VCI

tech2-vci-self-test-8

The VCI module self test result

Passed VCI selftest.





Part 2: GM Tech II Keypad self test

gm-tech2-keypad-test-1

Go to the Tech 2 menu and select F4: Tool options

gm-tech2-keypad-test-2

Then F3: Self test

gm-tech2-keypad-test-3

Before running the Tech 2 self test:
(1) Candi cannot be connected
(2) Aldl loopback should be connected (GM3000109)
(3) Failure to follow these instructions may invalidate the self test

gm-tech2-keypad-test-4

F3: Selectable main pcb

gm-tech2-keypad-test-5

Press Keypad

gm-tech2-keypad-test-6

And press key

gm-tech2-keypad-test-7

Note: In the last image, the actual key pressed is F0 and the final result is PASS – that’s normal

When you test the keypad, press F0-F1-F2-F3-F4-F5-F6-F7-F8-F9-EXIT-ENTER-in a good order! DO NOT SKIP ANY ONE.



Part 3: Tech 2 scan tool CANDI module self test



VERY IMPORTANT: Pls make sure of the connection of the OBD adapter, OBD main cable, CANdi module, Tech 2 scan tool and the power supply — ALL should be good



The power should be connected by the OBD port for  CANdi self test.

tech2-candi-self-test-1

tech2-candi-self-test-2

tech2-candi-self-test-3

tech2-candi-self-test-4

F4: Tool options

tech2-candi-self-test-5

F7: CANdi diagnostics

tech2-candi-self-test-6

F0: POST result

tech2-candi-self-test-7

Test status

tech2-candi-self-test-8

F1: Self test

tech2-candi-self-test-9

CANdi self test result

Pass selftest

There are two test results for CANdi module.

The one is Figure 8, and the other is Figure 10.





Part 4: GM Tech2 scanner RS232 self test

tech2-r232-self-test-1

Check the connection before R232 self test

tech2-r232-self-test-2
F4: Tool options

tech2-r232-self-test-3

F3: Self test

tech2-r232-self-test-4

Exit to continue

tech2-r232-self-test-5

F3: Selectable main PCB

tech2-r232-self-test-6

F2: Rs-232 loopback

tech2-r232-self-test-7

Rs232 test: Passed!



GM Tech 2 scanner tech support from http://www.obdii365.com/
