How to Reflash OBDSTAR X200 Pro2 Firmware?

When need a firmware reflash for OBDSTAR X200 pro2 oil reset tool?

1. Missing oil reset menu after software upgrade, you may need a firmware reflash

Obdstar X200 Pro2 Missing Oil Reset Menu

2. Failed to reset oil/service function, x200 pro2 gives error “Diag Abnormal exit! CODE:-3”

Obdstar X200 Pro2 Diag Abnomal Error Code 3

3. screen freeze and not working



The firmware reflash guide here can also be applied to OBDSTAR 5 inches tablets (iScan series, Odomaster, P50) and 7 inches tablets.

The procedure is the same, but uses different reflash program. Contact obdii365.com if you indeed need a firmware flash for the tablets mentioned.

Here is the x200 pro2 reflash file



Procedure:



Backup DP Software



Warning: Upgrading the firmware will clean up all the settings in the device and all the software in the DP. Users who have expired cannot download the software again through the one-click upgrade, so the software in the device needs to be backed up.

1. Insert a TF card with a capacity greater than 16G into the device to back up the DP software.

2. Click the main menu button on the main screen, select and enter the ES file manager.

Backup Obdstar X300 Dp Plus Software 1

3. Locate and long press the DP folder in the main interface of the ES file manager that opens, and then click the copy button.

Backup Obdstar X300 Dp Plus Software 2

4. Click the menu button, expand the local area, and select the homepage.

Backup Obdstar X300 Dp Plus Software 3

5. Select and click the external TF card, and then click the paste button. Wait for the copy to complete. After the firmware upgrade is complete, just overwrite the DP directory from the TF card to the device.

Backup Obdstar X300 Dp Plus Software 4





Preparations

1. Download firmware file above to be upgraded.

The firmware file name format is: dpXX.zip.

2.

A TF card with a capacity greater than 1G and a TF card reader. All files inside the card will be cleared during the operation, please backup first.

Flash Obdstar X300 Dp Plus 1



Making upgradable TF card ( Software SD_Firmware_Tool_v1.57.zip)

1. After inserting the TF card into the card reader, insert the card reader into the USB port of the computer.

2. Unzip the “SD_Firmware_Tool_v1.57.zip” and run the extracted “SD_Firmware_Tool.exe”

Reflash Obdstar X200 Pro2 Firmware 6

3. Follow the steps below.

Warning: All files in the TF card will be erased, if there are important files in the TF card, please back them up before operating.

Reflash Obdstar X200 Pro2 Firmware 7

Operating instructions

1). Make sure that your TF card information and capacity size can be seen, if not, please check that the TF card reader is properly inserted into the USB port of the computer.

2). Click the Firmware button to select the firmware file.

3). Click the Create button to start writing the firmware file to the TF card.



4. Wait for the prompt Creating upgrade disk ok. The upgradable TF card is made successfully.

Reflash Obdstar X200 Pro2 Firmware 8



Updating the firmware

Warning: please plug in the power adapter for the device and ensure that the power indicator is on. Do not power off during the upgrade process.

1. Insert the TF card into the device.

Flash Obdstar X300 Dp Plus 3

2. Make sure the device is plugged in and the power light is on. Long press the device power button and select Reboot

Flash Obdstar X300 Dp Plus 4

3. The device will automatically perform a firmware upgrade, and a progress bar will appear. Please wait.

Reflash Obdstar X200 Pro2 Firmware 11

4. When the screen displays “Doing Actions succeed. please remove the sdcard”, remove the TF card from the device. The device will automatically reboot and enter the system.

Reflash Obdstar X200 Pro2 Firmware 12

5. Firmware upgrade is completed.

Reflash Obdstar X200 Pro2 Firmware 13

Restart obdstar x200 pro2.

Done.

If x200 pro2 gave the error below which indicates reflash procedure failure, reflash again.

Obdstar X200 Pro2 Firmware Reflash Error
