GODIAG V600 vs. BMW ICOM A2 A3 Next Diagnostic Programming Tool

GODIAG V600-BM CAN-FD J2534 is a BMW professional diagnostic & programming / coding tool, it will replace GT1, OPS, OPPS, ICOM, ICOM A2, ICOM A3, ICOM NEXT.



V600-BM CAN-FD J2534 is able to access to all systems of new BMW car models to perform these functions: quickly read / clear fault codes, read dynamic data stream, active test, activation, components replacement, ECU replacement and upgrading, personalized settings, ECU programming, retrofitting and upgrading car configuration, SCN Coding, transmission initialization, enable the hidden features etc.

Godiag V600 Vs Bmw Icom A2 A3 Next 01

Godiag V600 Vs Bmw Icom A2 A3 Next 02



Look at this comparison table Godiag V600 Vs. BMW ICOM A2 / A3 / Next:

Items Godiag V600 BMW ICOM A1 A2 A3 NEXT
Image Godiag V600 Bmw Bmw Icom
Configuration Volume 12cm*6cm*2cm 25cm*12cm*4.5cm
Weight 300g 1.5kg
CPU high-speed processing High-speed processing 580 MHz MIPS, 32MBFLASH,

128MByte RA,built-in 32G

Average processing MPC5200 400MHZ
Low power consumption 3.6W 15w
Communication Wifi Built-in 150Mbps Wi-Fi 1T1R 802.11bgn Optional (or NO optional)
Point to point wifi Yes No
Connect wifi through router Yes With Wifi card
Network cable communication Yes Yes
USB Yes No
Protocol CAN-FD Yes No
DOIP Yes Yes
Functions BMW model diagnosis Yes Yes
ISTA-D (Diagnostic Software) Yes Yes
ISTA-P (Programming software) Yes Yes
ECU Programming Yes Yes
Coding Yes Yes
ECU Data Update Yes Yes
Optical fiber interface Yes Yes
Refit Yes Yes
For new BMW models, there is no need to turn on the ignition switch and smart key, and V600 can also enter the diagnostic mode Yes Yes
Features Add authorization to support more models Yes No
Authorization of JLR CAN FD Yes (Extra charge) No
Authorization of ODIS Yes (Extra charge) No
Authorization of Toyota TIS Yes (Extra charge) No
Authorization of Benz software Yes (Extra charge) No
Update Plan Phone APP is under development Yes No
Charge your phone by using tapy-c cable to connect V600 Yes No



Since Godiag V600 is claimed to replace BMW ICOM A2 / A3 / Next, what are its stand-out features? Let’s go on learning its details:



Firstly, look at Godiag V600 outlook, and this are its button description:

Godiag V600 Vs Bmw Icom A2 A3 Next 03



F1-Press it for more than 3s to reset factory setting

F2-Press it to restart system

Shell The shell is made of Polyamide.

Size:108 x 52 x 27 mm

Power Supply 7-32 V
Current Consumption About 300 mA when the power is 12V
CPU 580 MHz MIPS, 32MBFLASH, 128MByte RA, built-in 32G TF card(optional)
Operating System Linux
WiFi 150Mbps Wi-Fi 1T1R 802.11bgn
Bluetooth Bluetooth5.0/5.1
Interface USB 2.0
Ethernet 10/100Mbps
Indicator DoIP indicator
WIFI/BT indicator
ETH indicator
System indicator
Buzzer Sound Pressure Level:  MIN.80 dB
Temperature Working:-20 … +55°C, Storage:-20 … +85°C
Protection Rating Dust prevention and water resistance conform to IP52
Conform to

Electromagnetic Compatibility

Noise emissions:EN 55011,EN 55022
Anti-interference:EN 61000-6-2, EN 61000-6-4



  1. Godiag V600 supports professional diagnostic function for all BMW series:

1 series: 1’_E81/E81/E87/E88,1’_F20/F21

2 series: 2’_F22/F23,2’_F45/F46,2’_F87

3 series: 3’_E46,3’_E90/E91/E92/E93, 3’_F30/F31/F34/F35,3’_F80

4 series: 4’_F32/F33/F36,4’_F82/F83

5 series: 5’_E39,5’_E60/E61,5’_GT(F07), 5’_F10/F11/F18

6 series: 6’_E63/E64,6’_F06/F12/F13

7 series: 7’_E38,7’_E65/E66,7’_F01/F02/F03/F04, 7’_G11/G12

X series: X1_E84,X1_F48/F49,X3_E83,X5_E53,X5_70,X6_E71,

X6_E72,X3_F25,X5_F15/F85,X6_F16/F86,X4_F26

Z series: Z4_E85/E86,Z4_E89

I series: I’_I01/I02

MINI:  MINI_R50/R52/R53, MINI_R55/R56/R57/R58/R59/R60,  MINI_F55/F56



  1. Compatible Protocol: J2534, CAN-FD, DOIP, D-CAN, ISO14230, ISO15765, IFH, K-line ******



  1. Comes with ISTA-D, ISTA-P, Tool32, BMW Coding, ISPI, INPA, E-SYS, WINKFP, NCS-Expert Tool, and you can directly run them. no need to install any driver.

1) ISTA-D: used to read / erase fault codes, read the data flow, maintenance guidance, circuit diagram, wiring diagram and directly upgrade & program new models. It will activate the ignition switch without keys during diagnosis.

Godiag V600 Vs Bmw Icom A2 A3 Next 04



2). ISTA-P: an offline programming and coding software system, including the latest database for programming E, F, G, K, I series models

Godiag V600 Vs Bmw Icom A2 A3 Next 05



3). Engineer programming & coding software for F series vehicles

Godiag V600 Vs Bmw Icom A2 A3 Next 06



4). WINKFP: engineer programming software for E series vehicles.

5). NCS-Expert Tool: engineer programming software for E series vehicles.

6). INPA: engineering diagnostic software for E series vehicles.

Godiag V600 Vs Bmw Icom A2 A3 Next 07



7). Tool32: engineer command execution software for E series vehicles.

8). BMW Coding Tool: WINKFP NCS auxiliary software for importing engineer data for E series vehicles.



  1. Communicate in a variety of modes:

USB 2.0

DoIP indicator

Ethernet 10/100Mbps
WIFI/BT 802.11 indicator  150Mbps

ETH indicator
System Indicator

Godiag V600 Vs Bmw Icom A2 A3 Next 08



  1. Godiag BMW scanner Configuration:

Suitable power: 7-32 V

About 300 mA when the power is 12V

High-speed processor: CPU 580 MHz MIPS, 32MB FLASH,128MByte RA, Built-in 32G TF card(optional)

Godiag V600 Vs Bmw Icom A2 A3 Next 09

Enjoy!
